Mega Disk‘O

Product Description

The Double-Peak Flying Saucer is a high-speed aerial gliding attraction that combines rapid linear travel with continuous 360° gondola rotation, creating a dynamic flying experience across a 22-meter radius track layout. Featuring a distinctive double-peak track profile, riders experience alternating moments of weightlessness and acceleration as the gondola traverses the wave-like track at speeds up to 13 m/s (46.8 km/h), while simultaneously rotating at 12 rpm to amplify the sensation of flight and disorientation.
Designed for theme parks, amusement centers, and large-scale entertainment venues seeking a visually striking, high-throughput attraction, the Flying Saucer accommodates 22 passengers in a 6.5-meter diameter gondola. Despite its 75-meter track length, the ride’s compact 10-meter width footprint makes it suitable for elongated park parcels or linear entertainment corridors where space efficiency is critical.
Key Features:
  • Dual-Motion Flight Experience — High-speed linear travel (13 m/s) combined with rapid 360° gondola rotation (12 rpm) creates complex force vectors that simulate genuine flying sensations.
  • Double-Peak Track Profile — Wave-like track layout with two elevation peaks delivers alternating moments of airtime and acceleration, enhancing ride dynamics and repeatability.
  • High-Capacity Operation — 22-passenger gondola with efficient cycle times delivers strong hourly throughput for high-traffic venues.
  • Advanced Drive System — Dual-tire friction drive with variable frequency control ensures smooth, reliable operation with simplified maintenance (automatic tire tensioning for quick replacement).
  • Durable Power Delivery — Specialized sliding contact wire power supply system for gondola rotation — wear-resistant and long-lasting compared to traditional slip ring designs.

Parameter

Parameter Specification
Ride Type Mega Disc‘O
Equipment Category Gliding & Rotating
Equipment Grade Class B
Rider Capacity 22 passengers per cycle
Gondola Diameter 6.5 meters (21.3 feet)
Total Equipment Height 9.5 meters (31.2 feet)
Track Radius 22 meters (72.2 feet)
Maximum Operating Speed 13 m/s (46.8 km/h / 29.1 mph)
Gondola Rotation Speed 12 rpm (continuous)
Gondola Motion Type Simultaneous linear gliding + 360° self-rotation
Drive Power 60 kW
Drive System Dual-tire friction drive with variable frequency speed control
Tire Maintenance Automatic tensioning system for quick replacement
Power Delivery Specialized sliding contact wire (wear-resistant, long service life)
Control System Programmable logic controller (PLC) with real-time safety restraint monitoring
Safety Interlocks Restraint locking interlocked with launch sequence
Footprint (Operating Area) 10m × 75m (32.8ft × 246ft)
Design Service Life 10 years
Power Supply 3-phase 380V/50Hz (configurable to 440V/60Hz)
Certifications GB 8408-2018, GB/T 1866-2008, B-class equipment certification
Operating Temperature Range -10°C to +45°C (14°F to 113°F)
Humidity Tolerance Up to 95% RH (non-condensing)
Maintenance Interval Daily pre-operation inspection; monthly detailed maintenance; annual structural certification
Installation Time 25-35 days (with factory installation team on-site)
Commissioning & Training 5-7 days operator training + safety certification (included)
Optional Upgrades (1) Themed gondola fabrication, (2) Synchronized sound/light show package, (3) LED accent lighting, (4) Extended warranty (24/36 months)
